1991issue C031-12

Regime-gated MACD and stochastic rules inside a checklist

A checklist-process can first apply an adx-regime-gate, then use macd or a stochastic-oscillator according to the assigned confidence-factor. The inference-engine stops when an action-level fact is added to the knowledge-base.

  • Write the checklist-process as heuristic if-then rules that fire only when their conditions are already in the knowledge-base, then add a new fact rather than claim certainty.
  • An 18-period adx-regime-gate marks a trending or non-trending state, after which macd is the stronger signal in a trend and a nine-period slow stochastic-oscillator is the complementary oscillator when the market is not trending.
  • When several unused rules are eligible, conflict-resolution prefers the higher confidence-factor and the inference-engine stops at the first action-level fact.
  • Obtain each confidence-factor by testing an indicator separately in different market environments and recording its win/loss ratio, rather than assuming one weight fits every regime.
Entries in this reading3 entries
Pre-trade checklist43 readingsCurrent trackMACD115 readingsStochastic oscillator170 readings

Write the checklist as if-then facts

A trading-systems-decision-process is a repeatable sequence that turns market observations into an explicit entry, exit, or stand-aside decision. This combination uses a checklist-process: a written set of if-then gates that must be satisfied, in order, before a trade is taken or refused.

The checklist can be written as heuristic if-then rules. A rule fires only when its stated conditions are already in the knowledge-base, the inventory of current facts the checklist is allowed to consult. The rule then adds a new fact. It does not claim certainty.

Let the inference-engine pick one unused rule

The inference-engine scans eligible unused rules, prefers the unused rule with the higher attached reliability weight when more than one can fire, and stops once an action-level fact is obtained. That choice among several eligible rules is conflict-resolution. The attached reliability weight is the confidence-factor on the rule.

Forward-chaining starts from observed facts and works toward an action. Backward-chaining starts from a hypothesized action and asks whether the supporting facts can be established.

Classify regime before an indicator adds an action

An 18-period ADX reading is used as an adx-regime-gate. A reading above 15 that is at least as high as two days earlier marks a trending state. A reading below 30 that is no higher than two days earlier marks a non-trending state. The adx-regime-gate is used only to decide whether the market is treated as trending or non-trending.

MACD is treated as the stronger signal in a trending regime and the weaker signal in a non-trending regime. Complementary reliability weights are assigned to a nine-period slow stochastic-oscillator.

MACD buy and sell hypotheses are defined as the MACD line crossing above or below its signal line. The MACD line is the difference of two exponentially smoothed averages. The signal line is a further smoothing of that difference.

In a non-trending regime the nine-period slow stochastic-oscillator is used as an overbought or oversold oscillator. %K is taken from a nine-period window, and both %K and %D are further smoothed over three periods.

The stochastic buy rule requires both SK and SD below 30, with SK below SD, then SK crossing above SD next period. The sell rule requires both SK and SD above 70, with SK above SD, then SK remaining above SD next period.

Change the knowledge-base when market character changes

Rule reliability weights are obtained by testing an indicator separately in different market environments and recording its win/loss ratio. One confidence-factor is not assumed to fit every regime.

A constructed checklist can switch among different knowledge bases when market character changes, including the rate of change of the trend. It can combine technical readings with other indicator classes in one procedure.

MACD line and signal line versus Dow Jones Industrial Average

The MACD line and its signal line move through late 1989 into mid-1990, then lift with the late-1990 rally while the lower pane tracks the Dow. Values were read off the published Figure 3 plot, not from a table.
The MACD line and its signal line move through late 1989 into mid-1990, then lift with the late-1990 rally while the lower pane tracks the Dow. Values were read off the published Figure 3 plot, not from a table.Dow Jones Industrial Average · daily · 1989-11-01T00:00:00.000Z to 1990-07-31T00:00:00.000Z

Source uses exponential constants 0.15 and 0.075 for the MACD line and 0.2 for the signal line. Digitized from a low-resolution inverted scan; y-values are approximate and should not be treated as exact prints.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
4 of 80 in the MACD track
19911-3 pp.Next on MACDConstructing MACD signal lines and divergence testsThe MACD line is the arithmetic difference between two exponential moving averages of successive closing prices.
