Constructing next-bar MACD reversal prices

A reverse construction can return the implied next-bar price required for the MACD histogram to equal zero, for MACD to hold its current-bar value, or for MACD to cross its signal line. Implied-price formulas are specified for exponential and simple-average MACD, with worked lookbacks of 12, 26, and 9.

  • A reverse construction can return the implied next-bar price at which the MACD histogram would equal zero.
  • The same inversion can target a chosen MACD level, including zero or the current-bar value, and can plot a histogram-zero target, a level-hold target, and a signal-cross target together.
  • Implied-price formulas are specified for exponential MACD and for simple-average MACD, using lookbacks of 12, 26, and 9 and a smoothing constant of 2 divided by one plus the average length.
  • An example workflow places a next-bar stop at the histogram-zero target or the signal-cross target instead of waiting for the oscillator to print.
Entries in this reading1 entry
Current trackMACD115 readings

Solve MACD for a price on the forming bar

A reverse construction can return the implied next-bar price required for the MACD histogram to equal zero. That histogram-zero target is the solved price on the forming bar that would make the histogram print at zero.

The same inversion can target a chosen MACD level, including zero or the current-bar MACD value. The level-hold target is the implied next-bar price at which MACD would reprint its current-bar value.

Three implied next-bar prices

One study can plot three implied next-bar prices: MACD at zero, MACD unchanged from the current bar, and MACD crossing its signal line. Those three prices are the histogram-zero target, the level-hold target, and the signal-cross target.

The signal-cross target is the implied next-bar price at which MACD would cross its signal line.

Exponential and simple-average variants

Implied-price formulas are specified for both exponential MACD and simple-average MACD. Simple-average MACD is built from simple rather than exponential moving averages and has its own reverse-price formulas.

Worked constructions use lookbacks of 12, 26, and 9 for the short average, long average, and signal line. Exponential reverse-price formulas apply a smoothing constant of the form 2 divided by one plus the average length.

Inputs and an example stop workflow

Configurable inputs include the price series, fast period, slow period, signal period, averaging type, and whether to shift the implied-price plot.

An example workflow places a next-bar stop at the implied histogram-zero or signal-cross price rather than waiting for the oscillator to print.

AAPL daily next-bar MACD reversal prices, EMA 12-26-9

On the published eSignal daily AAPL chart, the orange line is the next-bar price that would make MACD meet its signal (histogram zero), the blue line is the next-bar price that would drive MACD itself to zero, and the green line is the next-bar price that would leave MACD unchanged. A trader can treat those three levels as accept-or-reject stops before the bar closes. At the labeled 24 Sep 2012 session the close is 673.54 while the signal-cross price sits at 704.81 and the MACD-zero price at 514.28, consistent with a slightly negative histogram (−1.98) that still needs a rally for a zero print. Earlier points were read off the dollar scale of that same figure.
On the published eSignal daily AAPL chart, the orange line is the next-bar price that would make MACD meet its signal (histogram zero), the blue line is the next-bar price that would drive MACD itself to zero, and the green line is the next-bar price that would leave MACD unchanged. A trader can treat those three levels as accept-or-reject stops before the bar closes. At the labeled 24 Sep 2012 session the close is 673.54 while the signal-cross price sits at 704.81 and the MACD-zero price at 514.28, consistent with a slightly negative histogram (−1.98) that still needs a rally for a zero print. Earlier points were read off the dollar scale of that same figure.AAPL · Daily · 2012-06-11T00:00:00.000Z to 2012-09-24T00:00:00.000Z

Screenshot study settings are Close, 12, 26, 9, EMA. The three right-edge labels (Close 673.54, orange 704.81, blue 514.28) and the session stamp 09/24/2012 are exact; all other prices are digitized from the 25-dollar grid and rounded to five dollars. Dates before 24 Sep 2012 are placed from the Jul/Aug/Sep axis marks and are good to about a week.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
