The next-bar price that forces a MACD signal-line cross

MACD is the difference between two exponential moving averages of price. Because a zero histogram is the same event as the MACD line meeting its signal line, that meeting can be solved as a next-bar price and plotted on the price pane.

  • MACD is the difference between a shorter-period and a longer-period exponential moving average of the input price series, with conventional lookbacks of 12, 26, and 9.
  • A zero histogram is algebraically the same event as the MACD line meeting its signal line, so that event can be solved as a next-bar price.
  • The implied next-bar price can be written from already known exponential averages and the two EMA weights, then plotted on the price pane.
  • Rebuilding MACD from simple moving averages yields companion next-bar prices for a direction change, a two-average cross, and a signal-line cross.
Entries in this reading3 entries
Current trackMACD115 readingsExponential smoothing117 readingsMoving average449 readings

What conventional MACD already contains

MACD is defined as the difference between a shorter-period and a longer-period exponential moving average of the input price series. The conventional MACD construction uses fixed lookbacks of 12, 26, and 9 for the fast average, slow average, and signal average.

The signal line is an exponential moving average of the MACD series, which is Exponential smoothing applied to MACD rather than to price, and the histogram is the spread between MACD and that signal line.

The cross as a next-bar price

A zero histogram is algebraically the same event as the MACD line meeting its signal line, which is the mapping solved for a next-bar price.

The next-bar price that forces a MACD-signal cross can be written from already known exponential averages and the two EMA weights, then plotted on the price pane.

An illustrated daily series

On the illustrated daily Apple series, a Friday close of 700.09 implied a next-session threshold of 693.546 for a MACD-signal cross.

The following session closed at 690.79, below that projected threshold, and MACD printed 15.0326 against a signal of 15.2085.

Companion prices from a Moving average rebuild

The same reverse-mapping idea applies when MACD is rebuilt from simple moving averages, yielding companion next-bar prices for a direction change, a two-average cross, and a signal-line cross. That rebuild replaces the exponential averages with Moving average lookbacks on the same price series.

In the compared window, the simple-moving-average version produced five price-threshold crosses while the exponential version produced seven.

Next-bar Apple price that forces a MACD signal-line cross

Traders can treat the red PMACDsignal path as a live strike: a next close above it implies MACD will cross up through its signal, and a close below it implies a bearish cross. Six such meetings with the daily close are visible from June to September 2012. Values were read off the published Apple daily chart; 700.09 and 693.546 are the printed last close and the one-bar-ahead projection.
Traders can treat the red PMACDsignal path as a live strike: a next close above it implies MACD will cross up through its signal, and a close below it implies a bearish cross. Six such meetings with the daily close are visible from June to September 2012. Values were read off the published Apple daily chart; 700.09 and 693.546 are the printed last close and the one-bar-ahead projection.AAPL · daily · 2012-06-06T00:00:00.000Z to 2012-09-24T00:00:00.000Z

Standard 12/26/9 settings on daily closes. The function is plotted one session ahead because it is a next-bar price. Only the 21 September close and the 24 September projection are labeled on the figure; remaining points are approximate readings from the raster.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
