Constructing MACD from lag-reduced exponential averages

A matching moving average and exponential average share the same long-run lag once the smoothing constant is 2/(w+1). TEMA1 and DEMA2 change how that smoother is built and seeded, then sit inside the usual short-minus-long MACD difference with a nine-period trigger.

  • A conventional moving average of period w has the same long-run lag as a matching exponential average: (w-1)/2, which equals (1-alpha)/alpha when the smoothing constant is 2/(w+1).
  • TEMA1 is three times the first nested exponential average minus three times the second plus the third, a composite required because a locally quadratic path has three regression coefficients.
  • DEMA2 updates a level with alpha and a trend with beta, seeds both from a linear fit on the first w points, and shows large overshoot at trend changes when the trend constant exceeds the level constant.
  • The MACD construction remains a short-minus-long smoother difference with a nine-period exponential average of that difference as the trigger, substituting TEMA1 or DEMA2 for the usual exponential averages.
Entries in this reading3 entries
Current trackMACD115 readingsExponential smoothing117 readingsMoving average449 readings

Matching the long-run lag

A conventional moving average of period w has the same long-run lag as a matching exponential average. That lag is (w-1)/2, which equals (1-alpha)/alpha when the smoothing constant alpha is 2/(w+1).

TEMA1 as a three-average composite

TEMA1 is defined as three times the first nested exponential average minus three times the second plus the third, and is therefore a composite rather than a plain triple exponential average.

A locally quadratic price path is modeled with three regression coefficients, which is why three nested exponential averages are required before TEMA1 can be formed.

Seeding TEMA1 from an initialization window

TEMA1 seeds are taken from a quadratic least-squares fit on the first 2w observations, then each nested average is started from a closed-form combination of those coefficients and alpha.

That opening stretch is the initialization window: typically one or two averaging periods used to seed recursive averages from a regression rather than from a single first price.

After about two averaging periods the TEMA1 path is essentially independent of the seed, so a first-observation start is adequate when the series is at least twice as long as the longest period w.

On a 26-week window TEMA1 hugs the series more closely than the one-parameter double exponential average, but it overshoots and undershoots more at major long-term turns.

Weekly NASDAQ close, 26-week TEMA1 and DEMA1

On the weekly NASDAQ close the 26-week TEMA1 composite tracks price more tightly than DEMA1, then overshoots and undershoots more at the large trend turns. Series come from the article’s stated seeds and overlay of price with those two 26-week smoothers.
On the weekly NASDAQ close the 26-week TEMA1 composite tracks price more tightly than DEMA1, then overshoots and undershoots more at the large trend turns. Series come from the article’s stated seeds and overlay of price with those two 26-week smoothers.NASDAQ · weekly · 1987-08-14T00:00:00.000Z to 1988-02-05T00:00:00.000Z

TEMA1 seeds from a quadratic fit on the first 2w points (w=26, α=2/(w+1)=0.074): a0=447.753, a1=-7.876, a2=0.146, giving EMA10=569.926, EMA20=714.912, EMA30=882.712 and TEMA10=447.754. DEMA2 seeds on the first w points are S0=448.352 and T0=-6.162.

DEMA2 as a two-constant smoother

DEMA2 splits the smoother into a level updated with alpha and a trend updated with beta. The level mixes the new observation with the previous level plus the previous trend.

DEMA2 initialization uses a linear fit over the first w points to set the starting level and slope rather than using the first raw observation alone.

Keeping the MACD short-minus-long difference

The MACD construction used here remains a short-minus-long smoother difference with a nine-period exponential average of that difference as the trigger, substituting TEMA1 or DEMA2 for the usual exponential averages.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
