1999issue C101-3

Second-stage MACD on relative-strength inputs

The featured construction applies a MACD difference line and a slower signal average to a relative-strength series rather than to raw price. Archive recipes build that series either as pairwise relative strength from two closes or as a bounded RSI input.

  • Second-stage MACD is a difference line and a slower signal line computed on a derived relative-strength series rather than on raw price.
  • Pairwise relative strength uses a paired chart, typically one equity series against one index series, and may apply ratio normalization so issues share a common numeric origin or terminus.
  • A bounded RSI input can fill the same second-stage slot after a Wilder-smoothed oscillator is built from separated one-period up and down changes.
  • Editorial view: a two-instrument price ratio and a bounded RSI can share one relative-strength label while they differ in units, scale, and default lengths.
Entries in this reading2 entries
Current trackMACD115 readingsRelative Strength Index186 readings

MACD on a relative-strength series

The featured construction applies a MACD difference line and a slower signal average to a relative-strength series rather than to raw price. In that form, second-stage MACD is only those two traces: the difference line is the fast exponential average minus the slow exponential average of the chosen relative-strength series, and the signal line is a further exponential average of the difference line, used as a comparison trace.

Pairwise relative strength

One two-instrument recipe forms relative strength from a length-10 lagged close ratio and a current close ratio scaled by 100, then feeds that series to a 12/25 MACD with a 9-period signal. The two-instrument version is described as requiring a paired chart, typically one equity series against one index series.

A spreadsheet version forms a 100-scaled price-to-index ratio, a 14-period lagged counterpart, then a 12-minus-25 exponential difference and a 9-period signal.

Ratio normalization

An issue-to-index price ratio is described as unnormalized, so its numeric range differs across issues. Dividing by the same ratio at another date can force the series to start or end at 100, or a 100-session lookback can be used. That rescaling is ratio normalization: successive issues then share a common numeric origin or terminus.

One formula set states that ordinary MACD is a 12-period minus 25-period exponential average of close, and the relative-strength version substitutes the normalized ratio for close.

Bounded RSI input

A second recipe first builds a bounded RSI input: a Wilder-smoothed oscillator from positive and negative one-period rates of change, with an adjustable lookback defaulting to 14 and bounded between 3 and 100. It then takes 12- and 25-period exponential averages and a 9-period signal.

A three-row worksheet version computes a 14-period RSI of close, a 12/26 MACD on that RSI row, and a 9-period signal of the MACD.

Worksheet, spreadsheet, and wizard forms

A wizard-style workflow allows changing MACD defaults of 12 and 26 and signal defaults of 9, 12, and 26, then replacing close with a relative-strength series against a second instrument. The archive therefore keeps one second-stage MACD label while the first-stage series, the lag used for scale, and the default average lengths are not the same in every recipe.

MACD of Microsoft relative strength versus the S&P 500

Microsoft’s close (upper pane) rose from the low thirties into the nineties while the lower pane tracks the MACD difference of pairwise relative strength versus the S&P 500 and its slower signal average. Both oscillator lines stay near a few thousandths, dip below zero around the late-1998 and early-1999 pullbacks, then peak near 0.0023 in April 1999 as the stock led the index. Values were read off the NeuroShell Trader chart, not from a printed table.
Microsoft’s close (upper pane) rose from the low thirties into the nineties while the lower pane tracks the MACD difference of pairwise relative strength versus the S&P 500 and its slower signal average. Both oscillator lines stay near a few thousandths, dip below zero around the late-1998 and early-1999 pullbacks, then peak near 0.0023 in April 1999 as the stock led the index. Values were read off the NeuroShell Trader chart, not from a printed table.MSFT versus S&P 500 · daily · 1998-01-01T00:00:00.000Z to 1999-07-31T00:00:00.000Z

NeuroShell applied MACD(12,25) and a 9-period signal to Relative Strength(Close, S&P 500). The raster is coarse, so coordinates are approximate and were sampled monthly.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
