Building classic divergence filters from RSI and MACD

Classic divergence is constructed when price makes a new high or low and the oscillator refuses to confirm that extreme. This article shows how to pair that price structure with RSI and MACD, split simple from compound patterns, and keep only extreme-zone nonconfirmations so the condition can be tested.

  • Classic divergence is constructed when an oscillator refuses to confirm a new price high or low. Reverse divergence is the opposite mismatch and is treated as a separate condition.
  • Simple divergence is a single unconfirmed price extreme. Compound divergence is built when price posts up to three new peaks or lows that the oscillator fails to confirm.
  • The extreme-zone filter ignores classic divergences whose oscillator values fall between 30 and 70.
  • Joint new highs or lows are a stable trend with no signal. Only a visible split is an unstable trend and is treated as a warning.
Entries in this reading3 entries
Current trackMACD115 readingsPrice-indicator divergence142 readingsRelative Strength Index186 readings

What classic divergence constructs

Classic divergence is constructed when an oscillator refuses to mirror a new price high or low. Reverse divergence is the opposite mismatch, in which price refuses to follow an oscillator extreme, and is treated as a separate condition.

The filter is built from that visible split between price and the oscillator. Reverse divergence is recorded separately and is not mixed into the classic-divergence rule.

How RSI and MACD enter the filter

Among oscillators applied to the same price series, RSI and momentum rate of change are described as most sensitive to divergence. MACD still shows usable divergence despite moving-average lag. Stochastics diverge less often.

The archive pairs the same price structure with RSI and with MACD when it constructs the classic-divergence marks.

Simple and compound patterns

Simple classic divergence is a single unconfirmed price extreme. That means a new high with a lower oscillator high or a double top, or a new low with a higher oscillator low or a double bottom.

Compound divergence is constructed when price posts up to three new peaks or lows while the oscillator fails to confirm all three. Those sequences are described in frequent, common, and rarely seen shapes.

Editorial: Simple and compound patterns should be split before the condition is tested, because they are different counts of unconfirmed extremes, not the same mark.

The extreme-zone filter

The construction rule is to ignore classic divergences whose oscillator values fall between 30 and 70. The cited ASA, euro, and Nasdaq cases are said to stay outside that band.

Editorial: Keeping only extreme-zone nonconfirmations is the step that makes the chart condition falsifiable. Mid-band splits are discarded at construction rather than spotted after the fact.

Stable trend and unstable trend

Joint new highs or lows are classified as a stable trend with no signal. Only a visible split between price and oscillator is classified as an unstable trend and treated as a warning that the prevailing move is suspect.

Constructed marks on the example charts

A weekly gold-trust example is presented as simple divergences on both RSI and MACD. Those simple divergences generate long-term buy and sell marks without waiting for a later trend break.

Euro and Nasdaq chart examples are used to show compound, and mixed compound-plus-simple, RSI and MACD divergences as constructed buy and sell marks.

The same construction across time frames

The same divergence construction is applied from long-term investment charts through short-term trading and intraday scalping. It is not claimed to catch every trend change.

ASA weekly price with RSI and MACD divergence marks, 1993–2002

Weekly ASA candlesticks fall from the mid-50s after 1994 into the mid-teens by 2000, then rebound toward 30 in 2002. MACD (top pane) and RSI (bottom pane) carry the simple and compound nonconfirmations the article treats as long-term buy and sell marks. Values were read from the plotted weekly chart, not from a table.
Weekly ASA candlesticks fall from the mid-50s after 1994 into the mid-teens by 2000, then rebound toward 30 in 2002. MACD (top pane) and RSI (bottom pane) carry the simple and compound nonconfirmations the article treats as long-term buy and sell marks. Values were read from the plotted weekly chart, not from a table.ASA (gold-based investment trust) · weekly · 1993-01-01T00:00:00.000Z to 2002-06-30T00:00:00.000Z

Approximate weekly closes digitized from the raster; price axis is logarithmic (60/50/40/30/20). RSI pane is scaled 0–100 with a mid-line at 50. No numeric table appears in the source.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
