Seeding DEMA2 filters to build a MACD signal

A MACD signal is assembled only after two DEMA2 filters are fully specified. Each filter takes its alpha and beta from a conventional lookback, starts from a regression-seed of weekly closes, and keeps the level-component and slope-component updates separate.

  • DEMA2 is a two-parameter filter. Its alpha and beta constants are taken from the conventional 26-period and 12-period MACD lookbacks.
  • Each filter starts from a regression-seed of weekly closes on time. The intercept seeds the level-component and the slope seeds the slope-component.
  • After that start, the level-component mixes the newest close with the prior level plus prior slope. The slope-component updates from the change in successive levels.
  • The macd-line is the 12-week DEMA2 filter minus the 26-week DEMA2 filter. The signal-average is a nine-period exponential smooth that places a 0.2 weight on the newest MACD value.
Entries in this reading3 entries
Linear regression112 readingsCurrent trackMACD115 readingsExponential smoothing117 readings

The archive sequence builds a MACD signal from two already specified DEMA2 filters. DEMA2 is a two-parameter smoother that updates a level with one constant and a companion slope with a second constant. The sequence sets those constants, starts each filter from a regression-seed, and keeps the level-component and slope-component updates separate. The macd-line is formed only after those filters are fully specified.

Set alpha and beta from the MACD lookbacks

DEMA2 is specified as a two-parameter filter controlled by a pair of smoothing constants, alpha and beta. Those constants are set from the conventional MACD lookbacks of 26 periods and 12 periods.

For the 26-period constants, alpha is 2/(26+1) and beta is 2/((0.5*26)+1). The 12-period pair uses the same two formulas with 12 in place of 26. Alpha is the primary smoothing weight taken from a chosen lookback as two divided by one plus that lookback. Beta is the secondary smoothing weight taken from half the same lookback.

Start each filter from a regression-seed

Each filter is started from a linear regression of weekly closing prices on time. The slow filter uses a 26-week fit and the fast filter uses a 12-week fit. That regression-seed is a linear fit of weekly closes on time used only to start the level and slope.

The level series is seeded with the regression intercept. The companion slope series is seeded with the regression slope.

Keep the level-component and slope-component separate

After seeding, the level-component is a weighted mix of the newest close and the previous level plus previous slope. That smoothed path steps forward from the latest observation plus the prior level and prior slope.

The slope-component uses the second constant on the change in successive levels. That term is treated as a 13-week trend on the 26-week filter and a six-week trend on the 12-week filter.

Form the macd-line after both filters exist

The MACD series is the 12-week DEMA2 filter minus the 26-week DEMA2 filter. That difference is the macd-line.

The difference is then passed through a nine-period exponential average that places a 0.2 weight on the newest MACD value. That second-stage exponential smooth is the signal-average.

Weekly Nasdaq with seeded DEMA2 filters and MACD

Weekly Nasdaq closes from early August 1987 through mid-February 1988, with the slow and fast DEMA2 level components (26-week and 12-week windows) and the MACD line formed after both filters are specified. Numbers are taken cell-for-cell from the source spreadsheet, including the crash weeks of October 1987.
Weekly Nasdaq closes from early August 1987 through mid-February 1988, with the slow and fast DEMA2 level components (26-week and 12-week windows) and the MACD line formed after both filters are specified. Numbers are taken cell-for-cell from the source spreadsheet, including the crash weeks of October 1987.NASDAQ · weekly · 1987-08-04T00:00:00.000Z to 1988-02-12T00:00:00.000Z

Each DEMA2 filter is regression-seeded on the first weekly close: slow window uses alpha 0.074 and beta 0.143 with slope -5.16 and intercept 448.35; fast window uses alpha 0.154 and beta 0.286 with slope -10.15 and intercept 479.48. Level (SM) and trend (TM) components update separately. The 9-period EMA of MACD is shown as a reference once it exists in the sheet.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
11 of 80 in the MACD track
19941-13 pp.Next on MACDConstructing MACD from lag-reduced exponential averagesA conventional moving average of period w has the same long-run lag as a matching exponential average: (w-1)/2, which equals (1-alpha)/alpha when the smoothing constant is 2/(w+1).
