Constructing a signed ten-point trend filter

A signed lookback score carries both direction and strength. A vertical-horizontal filter does not. A MACD reading checks whether thrust is fading. Keep the three outputs separate so trending is not treated as one blended number.

  • A trend-filter is a discrete signed rating: score plus one when the current close is at or above a lagged close, minus one when it is below, then sum ten comparisons so the total lies between plus ten and minus ten.
  • The specified lookback-block compares the current close with the closes from 11 through 20 sessions earlier, not with the most recent ten sessions.
  • A vertical-horizontal-filter carries neither the sign nor the direction of a trend, while the signed score carries both. MACD is kept as a separate check on fading thrust.
  • A pinned-extreme holds at plus or minus ten through a long trend. A shorter comparison span is more volatile, and a longer span is slower to respond.
Entries in this reading3 entries
Vertical Horizontal Filter3 readingsCurrent trackMACD115 readingsTrend filter137 readings

Three outputs, not one blended number

The archive presents a signed close-to-close rating beside other trend-strength constructions. The signed score is described as carrying both the direction and the strength of a run. A vertical-horizontal filter is described as carrying neither the sign nor the direction of a trend. A MACD reading is presented as a separate check on fading momentum as price enters a sideways range.

The signed rating is the trend-filter in this construction. The unsigned reading is the vertical-horizontal-filter. MACD is a moving-average-convergence-divergence oscillator used here only as a check on whether thrust is fading as price leaves a persistent run.

How the signed score is built

A signed trend rating can be formed by scoring plus one when the current close is at or above a lagged close and minus one when it is below. Ten such comparisons are then summed so the total lies between plus ten and minus ten.

One specified construction compares the current close with the closes from 11 through 20 sessions earlier, rather than with the most recent ten sessions. That set of lagged sessions is the lookback-block against which the current close is scored.

Length, companions, and response speed

Other trend-strength constructions discussed alongside this score include an average directional index, a linear-regression r-squared, and a vertical-horizontal filter. Each of those readings changes when the calculation length is changed.

A shorter comparison span is characterized as more volatile, with more frequent trend-change readings. A longer span is characterized as slower to respond.

Pinned extremes and sideways oscillation

The signed score is described as remaining at plus ten or minus ten through long trends. That state is a pinned-extreme: the rating stays at either bound for as long as a persistent run continues.

In sideways markets the same score is described as oscillating between those bounds, without staying at either extreme for long.

Signed trendscore on Intel, January–June 1993

A trader should see direction and strength in one signed reading: plus ten means the close beat every comparison 11 to 20 days back, minus ten the reverse. On Intel the score leaves plus ten in late January, sits there again through February into March, then pins at minus ten from 22 March through the mid-April break of 110. Points were read off the printed lower pane; the article gives no table.
A trader should see direction and strength in one signed reading: plus ten means the close beat every comparison 11 to 20 days back, minus ten the reverse. On Intel the score leaves plus ten in late January, sits there again through February into March, then pins at minus ten from 22 March through the mid-April break of 110. Points were read off the printed lower pane; the article gives no table.Intel (INTC) · Daily · 1993-01-01T00:00:00.000Z to 1993-06-13T00:00:00.000Z

Chande’s trendscore is the sum of ten +1/−1 close comparisons versus the window 11–20 days back, so the live reading is an even integer from −10 to +10. March 22 and April 15 are dates stated in the text; other dates are interpolated across the January–13 June 1993 window of the printed pane.

What the unsigned filter does not carry

A vertical-horizontal-filter is an unsigned trend-strength reading. It can rise or fall with persistence, but it does not carry the direction of the move.

The signed score is described as carrying both direction and strength. The two readings are not interchangeable, and the unsigned filter is not a signed trend rating under another name.

An illustrated companion path

On one illustrated series, a 28-session vertical-horizontal filter left its highs in early January near the same time as the signed score. The filter later formed a double bottom between February and early April and then rose, while the signed score flattened at minus ten somewhat earlier.

On that same illustrated series, a MACD reading peaked in early January and declined through April. The archive presents that path as a check on fading momentum as price entered a sideways range.

Optional construction variants

Construction variants include using fewer than 10 comparison days for a shorter horizon, 20 to 30 days for an intermediate horizon, and hourly observations instead of daily closes.

Optional style rules discussed include a zero-line cross, a one-to-three-session wait after a plus or minus 10 reading, a moving-average pairing, and delayed triggers when the score rises from minus ten through plus five or falls from plus ten through below 5.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
