Constructing a composite from weighted smoothed rates of change

The composite is built in three layers. Compute four zero-centered rates of change, smooth each series with a simple or exponential moving average, then multiply by fixed weights and add the products. Horizon sets publish lookbacks, smoothers, and weights for short, intermediate, and long sampling on daily, weekly, or monthly bars.

  • The composite has three layers: four rate-of-change series, a simple or exponential moving average on each series, and a weighted sum of the smoothed series.
  • Rate of change is the current close divided by the close n periods earlier, multiplied by 100, then reduced by 100 so the series is centered on zero.
  • Exponential smoothing uses a constant of two divided by one more than the lookback length, seeds the first observation, and begins updating on the next period.
  • Horizon sets bundle four lookbacks, four smoothers, and weights of 1, 2, 3, and 4 for short, intermediate, or long sampling on daily, weekly, or monthly bars.
Entries in this reading3 entries
Current trackRate of Change50 readingsExponential smoothing117 readingsMoving average449 readings

Three construction layers

The composite is built in three layers: compute four rate-of-change series, smooth each series with a simple or exponential moving average, then multiply the smoothed series by fixed weights and add the products.

Editorial: treat those steps as three separable construction choices. A reader can rebuild or swap the rate-of-change transform, the smoother, or the weight schedule without treating the finished series as a single opaque formula.

A zero-centered rate of change

Rate of change is the current close divided by the close n periods earlier, multiplied by 100, then reduced by 100 so the series is centered on zero.

In this workflow, rate of change is a close-to-close percentage change over a stated lookback, shifted so the series is centered on zero.

Four weekly S&P 500 rates of change that feed the short-term KST

The four zero-centered weekly rates of change that later get smoothed and weighted into the short-term KST. The 3-week series is the noisiest; the 10-week series stays negative through March and only turns up in April. Every point is copied from the sidebar spreadsheet of S&P 500 weekly closes, 3 January through 8 May 1992.
The four zero-centered weekly rates of change that later get smoothed and weighted into the short-term KST. The 3-week series is the noisiest; the 10-week series stays negative through March and only turns up in April. Every point is copied from the sidebar spreadsheet of S&P 500 weekly closes, 3 January through 8 May 1992.S&P 500 · weekly · 1992-01-17T00:00:00.000Z to 1992-05-08T00:00:00.000Z

Short-term weekly KST uses ROC lengths 3, 4, 6 and 10 weeks. The printed weighted sum appears only on 1 May (6.26) and 8 May 1992 (10.71), too few points to plot as the finished composite.

An explicit smoother

A moving average is a simple or exponential smoother applied to each rate-of-change series before the series are combined. Exponential smoothing is a recursive average that blends the newest observation with the prior average using a smoothing constant.

The smoothing constant equals 2 divided by one more than the lookback length. For a three-period lookback that constant is 0.50.

Each new exponential average equals the prior average plus the smoothing constant times the gap between the new observation and the prior average. Because the first period has no prior exponential average, the first observation seeds the series and smoothing begins on the next period.

A weighted sum

The last construction step is a weighted sum: each smoothed rate-of-change is multiplied by a preset weight and the four products are added.

Published horizon sets

A horizon set is a published bundle of four lookbacks, four smoothers, and four weights chosen for short, intermediate, or long sampling. Suggested parameter sets exist for short, intermediate, and long horizons and may be computed on daily, weekly, or monthly sampling.

In the short-term weekly exponential set, the four rate-of-change lengths are 3, 4, 6, and 10, the matching exponential averages are 3, 4, 6, and 8, and the weights applied before the sum are 1, 2, 3, and 4. The worked weekly example applies exponential constants of 0.5, 0.4, 0.29, and 0.22 to those four smoothers, consistent with 2/(n+1) for n of 3, 4, 6, and 8.

The short-term daily set uses rate-of-change lengths 10, 15, 20, and 30, simple averages of 10, 10, 10, and 15, and the same 1-2-3-4 weights.

The long-term weekly exponential set uses rate-of-change lengths 39, 52, 78, and 104, exponential averages of 26, 26, 26, and 39, and weights 1, 2, 3, and 4.

Editorial: the listed sets share weights of 1, 2, 3, and 4, so the rising schedule can stay fixed while the lookbacks and smoothers change with horizon and sampling.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
