Constructing a composite from weighted, smoothed rate-of-change windows

The indicator is assembled in three operations: four zero-centered rate-of-change series, an independent simple or exponential moving average on each series, and a weighted sum that gives the longest window the largest integer weight. Archive recipes fix those choices for daily, weekly and monthly sampling.

  • The indicator is assembled in three operations: compute four rate-of-change series, smooth each series with a simple or exponential moving average, then form a weighted sum of the smoothed series.
  • Each rate-of-change divides the current close by the close a fixed number of periods earlier, multiplies by 100 and subtracts 100, so the series is centered on zero.
  • A moving average is applied independently to each window. Exponential smoothing uses the smoothing-constant 2/(n+1); a 3-period span uses 0.50, and the first observation seeds the average.
  • Composite-weighting then uses 1, 2, 3 and 4 so the longest window contributes the most. Parameter sets exist for daily, weekly and monthly sampling, including a long-term weekly set of rate-of-change lengths 39, 52, 78 and 104.
Entries in this reading3 entries
Current trackRate of Change50 readingsExponential smoothing117 readingsMoving average449 readings

Three operations

The indicator is assembled in three operations. Compute four rate-of-change series. Smooth each series with a simple or exponential moving average. Then form a weighted sum of the smoothed series.

Four zero-centered rate-of-change windows

A rate-of-change is a momentum reading that divides the latest close by the close a fixed number of periods earlier, scales the ratio by 100, and subtracts 100 so the series is centered on zero. The construction uses four such series, each with its own lookback.

One short-term weekly recipe uses rate-of-change lengths 3, 4, 6 and 10. Parameter sets are also specified for daily and monthly sampling, and a long-term weekly set uses rate-of-change lengths 39, 52, 78 and 104.

A moving average on each window

A moving average is a simple or exponential smoother applied independently to each rate-of-change window before those windows are weighted and added. Exponential smoothing is a recursive average that blends the newest observation with the prior average using a constant equal to 2 divided by one more than the span.

The smoothing-constant is the update fraction 2/(n+1) that sets how quickly an exponential average responds when the span is n. A 3-period span therefore uses 0.50. The exponential update adds the smoothing-constant times the gap between the new observation and the prior average. The first observation seeds the average and smoothing begins on the following bar.

The short-term weekly recipe uses exponential spans 3, 4, 6 and 8. In the weekly construction walk-through, the 4-, 6- and 8-period exponential constants appear as 0.4, 0.29 and 0.22.

Composite-weighting after the smoothers

Composite-weighting is the final sum in which four independently smoothed momentum windows receive increasing integer weights so the longest window contributes the most. After smoothing, the four series are combined as one times the shortest window plus two, three and four times the successively longer windows. The short-term weekly recipe uses weights 1, 2, 3 and 4.

Parameter sets are specified for daily, weekly and monthly sampling and for both simple and exponential smoothing.

Four weekly S&P 500 rate-of-change windows used to assemble short-term KST

Each series is a zero-centered weekly rate of change on the S&P 500, so a trader can see the four lookbacks disagree in both size and sign before any smoother or weight is applied. The 3-week window swings first; the 10-week window stays negative through the March–April slide and only turns up in May. Every point is the exact cell value from the source short-term weekly spreadsheet, not a reading off a plotted curve.
Each series is a zero-centered weekly rate of change on the S&P 500, so a trader can see the four lookbacks disagree in both size and sign before any smoother or weight is applied. The 3-week window swings first; the 10-week window stays negative through the March–April slide and only turns up in May. Every point is the exact cell value from the source short-term weekly spreadsheet, not a reading off a plotted curve.S&P 500 · Weekly · 1992-01-17T00:00:00.000Z to 1992-05-08T00:00:00.000Z

Short-term weekly recipe from the parameter table: 3-, 4-, 6- and 10-week ROC. The printed spreadsheet defines each n-week ROC as 100×(this close / close n−1 weeks earlier)−100. Those four series are later EMA-smoothed and summed with weights 1, 2, 3 and 4; the finished weighted sum appears on only the last two rows and is omitted.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
