Three-gate centered strength in market-breadth construction

This archive construction keeps a relative breadth residual, a new-high strength gate, and a new-low strength gate on separate centered-strength scales so a close-to-close reversal is allowed only when all three conditions hold.

  • Six aligned daily series feed the construction, but only the traded large-cap index is required to stay visible.
  • Exponential pre-smoothing is applied to new-high counts, new-low counts, and the advance-decline ratio before any centered-strength transform.
  • A three-gate reversal allows a close-to-close flip only when the relative breadth residual and both new-extreme gates are true together.
  • Companion plots reuse the same thresholds and lookbacks so each gate can be inspected on its own screen-scaled pane.
Entries in this reading3 entries
Exponential smoothing117 readingsCurrent trackMarket breadth120 readingsStochastic oscillator170 readings

Six aligned daily series

The construction uses six aligned daily series: a traded large-cap index, a second price index kept only as a relative-strength benchmark, exchange 52-week new highs, exchange 52-week new lows, advancing issues, and declining issues. Only the traded series is required to stay visible.

Centered strength after pre-smoothing

A reusable strength transform rescales any series to a minus-fifty to plus-fifty band by taking one hundred times the location of the current value between the lookback low and high, then subtracting fifty. That mapping is centered strength: a lookback range placed so zero is the midpoint of recent values.

Raw internals are not passed straight into that transform. New-high and new-low counts receive exponential pre-smoothing over three periods. The advance-decline ratio, defined as advancing issues minus declining issues divided by their sum, receives exponential pre-smoothing over ten periods. Only after those averages are the series converted to centered strength.

The same centered-strength value can be obtained as stochastic-style strength. Apply a fast stochastic to one series by repeating that series in every price slot, then subtract fifty from the zero-to-one-hundred result.

The residual and the new-extreme gates

Advance-decline relative strength is the ten-period centered strength of the smoothed advance-decline ratio minus the ten-period centered strength of the second price index. That difference is the relative breadth residual.

The new-high strength gate is the centered strength of the exponentially smoothed 52-week new highs, compared with explicit buy and sell bounds. The new-low strength gate is the same construction on exponentially smoothed 52-week new lows.

A buy-side close reversal requires all three of: relative advance-decline strength at or above the buy threshold, new-low strength at or below its buy bound, and new-high strength at or above its buy bound. A sell-side close reversal requires all three of: relative advance-decline strength at or below the sell threshold, new-low strength at or above its sell bound, and new-high strength at or below its sell bound. That joint test is the three-gate reversal.

The first complete input list sets the buy residual threshold at 5, the sell threshold at minus 35, the new-low strength lookback at 40 periods, the new-high strength lookback at 10 periods, new-low bounds of minus 10 and 30, and new-high bounds of minus 10 and 0.

Buy and sell levels on the three centered-strength gates

A close-to-close reversal is allowed only when the A-D residual, new-low strength, and new-high strength all clear their own gates on the shared −50 to +50 scale. Buy needs the residual above +4, new-low strength at or below −10, and new-high strength at or above −10; sell needs the residual at or below −40, new-low strength at or above +30, and new-high strength at or below 0. Those six levels are the SMARTrader coefficient rows in the source table and match the TechniFilter signals in the same tip.
A close-to-close reversal is allowed only when the A-D residual, new-low strength, and new-high strength all clear their own gates on the shared −50 to +50 scale. Buy needs the residual above +4, new-low strength at or below −10, and new-high strength at or above −10; sell needs the residual at or below −40, new-low strength at or above +30, and new-high strength at or below 0. Those six levels are the SMARTrader coefficient rows in the source table and match the TechniFilter signals in the same tip.S&P 500 with NYSE advances, declines, new highs, new lows, and DJIA · Daily

The TradeStation listing in the same tip uses Brs=5 and Srs=−35 rather than 4 and −40. New-low strength is centered over 40 days; new-high strength and the residual use 10 days. Each strength series is a fast stochastic of a pre-smoothed input, then shifted by −50.

Companion plots on matching scales

Companion plots of the residual, new-high strength, and new-low strength reuse the same thresholds and lookbacks as the reversal rules so each gate can be inspected on its own screen-scaled pane.
