Constructing trendlines and channels from explicit swings

A trendline, price-channel, or horizontal-zone begins with a named swing-selection rule. The same rule later decides whether price has broken the structure or only nicked it.

  • An uptrend-line connects a sequence of significant lows while price is forming higher lows and higher highs. A downtrend-line connects a sequence of significant highs while price is forming lower highs and lower lows.
  • When significant swings are hard to locate, horizontal lines through recent highs and lows map a sideways zone, with the lower boundary treated as support and the upper boundary treated as resistance.
  • A price-channel is a trendline plus a parallel companion line. Placement is approximate, and the practical test is that the majority of price action remains inside the band.
  • Swing anchors can be chosen with a zigzag-filter, a high-low-window, or a linear-regression-midline, so a later break is judged against the same construction rule.
Entries in this reading3 entries
Current trackPrice channel77 readingsTrendline128 readingsSupport and resistance170 readings

Start with a stated swing rule

Editorial reading: treat every trendline, price-channel, and horizontal-zone as a construction that begins with an explicit swing-selection rule. A later break is then judged against that same rule, not against a line that has been redrawn after the fact.

A trendline is a straight line through a chosen sequence of swing highs or swing lows that states the working direction of price. The archive workflow names how those swings are selected before the line is drawn.

Uptrend and downtrend lines

An uptrend-line is constructed by connecting a sequence of significant lows and is used when price is forming higher lows and higher highs.

A downtrend-line is constructed by connecting a sequence of significant highs and is used when price is forming lower highs and lower lows.

Swiss franc June 1995 holding a long-term uptrend

June 1995 Swiss franc futures climb from the mid-76s in January to the high-88s by early spring, then pull back to the low-82s in May and hold. The rising reference line is the long-term support drawn through the two circled swing lows; price stays above it for the whole window. Weekly levels were read from the daily bar chart’s cents scale; the final 85.85 print is the 19 June session quoted on the screen.
June 1995 Swiss franc futures climb from the mid-76s in January to the high-88s by early spring, then pull back to the low-82s in May and hold. The rising reference line is the long-term support drawn through the two circled swing lows; price stays above it for the whole window. Weekly levels were read from the daily bar chart’s cents scale; the final 85.85 print is the 19 June session quoted on the screen.CME Swiss franc June 1995 futures · Daily bars, weekly samples · 1995-01-16T00:00:00.000Z to 1995-06-19T00:00:00.000Z

Digitized from daily OHLC bars on a labeled 74–89 cents scale. Samples are weekly and rounded to the nearest half-cent except the printed 19 June close. Steeper short-term uptrend lines on the same figure are omitted so the long-term line stays readable.

Horizontal zones when swings are unclear

When significant swing highs and lows are hard to locate, horizontal lines through recent highs and lows map a sideways zone. The lower boundary is treated as support. The upper boundary is treated as resistance.

Support is the lower constructed boundary where buying interest is expected to appear if the structure still holds. Resistance is the upper constructed boundary where selling interest is expected to appear if the structure still holds.

Parallel lines make a channel

A price-channel is constructed by drawing a line parallel to an existing trendline so price is expected to travel between the two boundaries. The upper line is treated as resistance and the lower line as support.

Channel placement is approximate rather than exact. The practical construction test is that the majority of price action remains inside the band.

Three rules for choosing anchors

A zigzag-filter can select trendline anchors by suppressing moves smaller than a chosen percentage or point threshold. A swing is recorded only after price has already traveled that amount.

A percentage zigzag-filter is preferred to a fixed-point filter because a one-point move may not scale with changing volatility. A 5% filter can erase nearly all usable swings, while a 0.15% filter can mark almost every fluctuation.

A linear-regression-midline can be fit by least squares between a chosen start and end point, such as the most recent 20 days. Parallel lines around that midline can form a channel.

A high-low-window marks the lowest low or highest high of successive fixed-length windows, then connects those marks. Windows of four to six days are suggested for shorter-term lines and windows of six to fifteen days for longer-term lines.

Judging a later break

A slight penetration of a constructed trendline is not treated as a decisive break unless price closes through the line or remains through it for several days.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
