2003issue C101
Two-anchor trendline construction without cut-through
A trendline is a straight chart segment that joins two legally chosen same-side swing points. Lock those anchors, reject any cut-through, and treat a later cross as a redraw-or-confirm fork rather than a finished reversal.
- An uptrend-line is built from the lowest low to the highest low immediately preceding the highest high. A downtrend-line is built from the highest high to the lowest high immediately preceding the lowest low.
- A connecting-point is invalid if the finished segment passes through any intervening price bar. A cut-through of even one bar is treated as a sign that the segment is probably too long for the actual trend.
- As a bull or bear market extends, the line often has to be redrawn rather than left fixed. Penetration can warn that the trend is ending, or it can mean only that a new drawing is required.
- After a break, confirmation is often taken from another tool or from price action such as a follow-through day or a retest of the line as support or resistance. Hindsight drawing makes a finished trendline look more reliable than a line that still has to be updated.
Start with two legal anchors
A trendline is a straight chart segment joining two legally chosen same-side swing points. After those anchors are set, the segment is used as a condition that price can test or cross.
An uptrend-line is constructed from the lowest low to the highest low immediately preceding the highest high, provided no intervening bar is cut. A downtrend-line is constructed from the highest high to the lowest high immediately preceding the lowest low, provided no intervening bar is cut.
The second swing is the connecting-point. That choice is invalid if it forces the finished segment through any price between the two anchors.
When the line is crossed
As a bull or bear market extends, the line often has to be redrawn rather than left fixed. Hindsight drawing makes a finished trendline look more reliable than a line that still has to be updated as the move unfolds.
Penetration is price crossing a previously valid segment. That cross can be an early reversal warning, but it can also mean only that the line needs to be redrawn.
After a break, confirmation is often taken from another tool or from price action such as a follow-through day or a test of the line as support or resistance. A later return that treats the old line as the opposite side of the market is a retest. It is confirming price action, not the break itself.
A historical retest on December gold
On the December gold chart, prices broke beneath the line in early June, rose to test it in mid-June, then retreated after that test. In that sequence the mid-June return is a retest of the broken segment, not the break itself.
December gold daily closes around the June trendline break
Closes are approximate to the nearest dollar from a dark candlestick pane. Wicks reach nearer 316 and 372 than the closes do. Only the 352.80 last price is printed on the axis.
TradersWeek editorial reading
This is a TradersWeek editorial reading, not an archive claim. Use the two-anchor rule as a construction checklist: lock two legal same-side swings, discard any segment that creates a cut-through, and only then treat the line as a live condition.
A later penetration is a fork, not a finished reversal. Either redraw from a new legal pair of anchors, or wait for confirmation from another tool or from price action such as a follow-through day or a retest. Do not read a hindsight line as if it had been that stable while the move was still unfolding.
