Constructing a log-change probability line for trend and range rules

A continuation probability is built from the average and root-mean-square of log price changes and rescaled to a 0-1 reading. That line is then used only through a precommitted trendline break, a range extreme, or a two-series confirmation.

  • A continuation probability divides the average log change of a price series by the root-mean-square of those log changes, then rescales the ratio so the reading sits on a 0-1 scale.
  • The same construction is applied without change to monthly index bars, monthly single-name bars, and daily bars, so the filter is specified as timeframe-agnostic.
  • A trendline on the probability series, highs and lows treated as support and resistance, or a second-series confirmation can be named in advance as the only event that may open, close, or skip a trade.
  • A reversal rule that buys below 0.2 or sells above 0.8 still requires a stop, because those extremes can persist rather than turn.
Entries in this reading3 entries
Current trackTrendline128 readingsSupport and resistance170 readingsRule-based entry174 readings

The archive forms a continuation probability by dividing the average log change of a price series by the root-mean-square of those log changes, then rescaling as ((average / RMS) + 1) / 2 so the reading sits on a 0-1 scale. The point of the construction is to put a continuation reading on the chart as something that can be drawn on, not only watched.

The same construction on any bar scale

The same construction is applied without change to monthly index bars, monthly single-name bars, and daily bars, so the filter is specified as timeframe-agnostic rather than tied to one chart scale.

On monthly Nasdaq-100 bars the probability line is presented as marking both multi-month advances and abrupt reversals that fixed-lookback oscillators such as RSI or stochastics often smear.

NASDAQ 100 monthly continuation probability

The 0–1 continuation reading stays weak through the 2000–02 NDX decline, then holds high during the 2003–04 advance and only briefly collapses on sharp monthly reversals. Traders can treat the line as a constructed probability, not a price overlay. Every point is the published P column from the source workbook, P = ((average log change / RMS of log changes) + 1) / 2.
The 0–1 continuation reading stays weak through the 2000–02 NDX decline, then holds high during the 2003–04 advance and only briefly collapses on sharp monthly reversals. Traders can treat the line as a constructed probability, not a price overlay. Every point is the published P column from the source workbook, P = ((average log change / RMS of log changes) + 1) / 2.NDX · monthly · 2000-05-01T00:00:00.000Z to 2006-04-03T00:00:00.000Z

P is first published in May 2000 after the workbook has enough monthly log-change history to form AVG and RMS. AVG is the mean of LN(close/prior close); RMS is (SUMSQ/COUNT)^0.5 of those log changes.

A trendline on the probability series

A trendline is a line drawn across successive lows or highs of the continuation-probability series so a later break of that line can falsify the active up or down hypothesis.

On daily Microsoft bars an upward trendline on the probability series is drawn from a low near 0.043 to a later mid-range point. That line is treated as broken on 15 March 2006, ending that uptrend hypothesis.

Highs and lows as support and resistance

Support and resistance means high and low extremes of the probability line, or of price read against that line, treated as barriers where a continuation reading is exhausted and a reversal hypothesis becomes testable.

On daily QQQQ bars the probability line's own highs and lows are paired with support and resistance to frame trades while price is moving sideways.

One reading, three precommitted procedures

A rule-based entry is a precommitted threshold or two-series confirmation that turns the same probability reading into buy, sell, or stand aside as one testable procedure.

One fully specified entry rule buys when the daily QQQQ probability crosses above 0.5 and sells when it crosses below 0.5.

A second rule anticipates reversals from readings below 0.2 (buy) or above 0.8 (sell) and requires a stop, because those extremes can persist rather than turn.

A two-series rule buys only when the S&P 100 probability is rising while the VIX probability is falling, and sells only when those conditions reverse. Otherwise the procedure does not fire.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
