2015issue C0159-60

Bandedge trend filter construction with inverse crossover rules

One trend filter is shown at bandedge 20 and at bandedge 50, then used for trend-following rules or inverse rules without changing the filter. Decision tables turn the active setting into buy or sell crossovers, fills are placed on the next bar after a close, and each strategy keeps its own long and short transaction summary.

  • A swing-oriented example sets bandedge to 20, and the same trend filter is also shown with bandedge 50 as an alternative lookback.
  • Inverse rules reverse the trend-following long and short assignments instead of changing the filter.
  • Decision tables encode both strategies from the active bandedge setting and issue buy or sell crossover signals.
  • Because signals are taken on the close, simulated fills are placed on the next bar, and each strategy has its own long and short transaction summary.
Entries in this reading3 entries
Trend following89 readingsCurrent trackMomentum strategy103 readingsTrend filter137 readings

A preprogrammed buy and sell procedure

The archive frames a trading system as a preprogrammed procedure that issues automated buy and sell signals instead of leaving the decision to discretionary interpretation.

The construction uses one trend filter. A trend filter is a bandedge-tuned construction that turns an ordered price series into a regime edge used for crossovers. Those crossovers then drive a trend-following procedure or inverse rules. The filter itself is not changed when the rule polarity changes.

Editorial: TradersWeek presents the filter, the rule polarity, the fill assumption, and the ledgers as separate design choices so each can be inspected on its own.

Bandedge settings for one trend filter

Bandedge is the lookback-style parameter that sets how quickly that filter edge responds. A swing-oriented construction example sets the filter's bandedge parameter to 20. The same filter construction is also shown with bandedge set to 50 as an alternative lookback.

Trend-following rules and inverse rules

Trend following is the rule set that takes a filter crossover in the direction of the indicated move. A momentum strategy is a complete long and short procedure driven by the same filter crossovers, including an inverted-rule variant.

Countertrend rules are formed by inverting the proposed trend-following entry and exit logic rather than by changing the filter itself. Inverse rules are the same crossover events with long and short assignments reversed for a countertrend procedure. Both rule sets can be inspected together at any chosen bandedge setting.

Decision tables and crossover signals

Decision tables encode the two strategies from the active bandedge setting and generate buy or sell crossover signals. A decision table is an explicit mapping from the current filter state to long, short, or flat actions.

Close confirmation and next-bar execution

Because the system is computed on bar close, simulated fills are placed on the bar after a crossover. Next-bar execution is the fill assumption that a close-confirmed crossover is acted on at the following bar.

Editorial: TradersWeek treats that following-bar fill as a stated execution convention, not as a description of live market impact.

Transaction summaries for long and short ledgers

Each strategy has its own transaction summary so long and short positions can be reviewed separately. A transaction summary is a per-strategy ledger that separates long and short trades for inspection.

Bandedge-20 inverse strategy: long versus short net change

On Raytheon from 10 June 2003 through 23 July 2014 the inverse (countertrend) rules at bandedge 20 produced a +38.25 net on 124 long trades and a −26.05 net on 124 short trades, for about +12.20 overall. Traders should notice the split: longs won 56 of 124 and shorts only 34 of 124, so the same filter and inverted crossovers did not treat both sides equally. Totals come from the Figure 12 transaction-summary tables, not from a redrawn equity curve.
On Raytheon from 10 June 2003 through 23 July 2014 the inverse (countertrend) rules at bandedge 20 produced a +38.25 net on 124 long trades and a −26.05 net on 124 short trades, for about +12.20 overall. Traders should notice the split: longs won 56 of 124 and shorts only 34 of 124, so the same filter and inverted crossovers did not treat both sides equally. Totals come from the Figure 12 transaction-summary tables, not from a redrawn equity curve.Raytheon Company (RTN) · Daily · 2003-06-10T00:00:00.000Z to 2014-07-23T00:00:00.000Z

Fills are on the bar after a close-based crossover. Period is 06/10/2003–07/23/2014; size is one share; 28 longs and 6 shorts were still open and marked to the last bar. Inverse rules, not trend-following.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
