Constructing a volume zone oscillator with a moving-average and Average Directional Index regime filter

The featured construction pairs a volume zone oscillator with a 60-bar exponential moving average of the close and a 14-bar Average Directional Index. Moving-average location and the Average Directional Index level label trending versus nontrending conditions first, so the same oscillator can be read in both trending and oscillating markets.

  • Combine a volume zone oscillator with a 60-bar exponential moving average of the close and a 14-bar Average Directional Index so the same oscillator can be read in trending and oscillating conditions.
  • Treat moving-average location and an Average Directional Index reading of 18 as a regime filter: above 18 is trending, below 18 is nontrending, and oscillator rules fire only after that label is set.
  • Read oscillator persistence between -40 and zero as selling pressure exceeding buying pressure, and persistence between zero and +40 as the first wave of an advance.
  • Keep the oscillator lookback configurable from the chart, and treat overbought, oversold, and zero-line crossings as explicit, alertable conditions.
Entries in this reading3 entries
Current trackAverage Directional Index71 readingsVolume-price analysis129 readingsMoving average449 readings

A single oscillator for two market conditions

The featured construction combines a volume zone oscillator with a 60-bar exponential moving average of the close and a 14-bar Average Directional Index so the same oscillator can be read in both trending and oscillating conditions. Volume-price analysis here is the oscillator reading. The moving average and the Average Directional Index supply the regime label that sits in front of that reading.

How the regime filter is labelled

In the published TradeStation implementation, an Average Directional Index reading above 18 is treated as trending and a reading below 18 is treated as nontrending. Price location relative to the 60-bar exponential moving average of the close is the other half of the regime filter. Oscillator rules fire only after that trending or nontrending label is in place.

How the oscillator classifies pressure

The same construction treats oscillator persistence between -40 and zero as selling pressure exceeding buying pressure, and persistence between zero and +40 as the first wave of an advance. The indicator implementation includes alerts when the oscillator crosses user-set overbought and oversold levels.

Volume zone oscillator on the Dow, January–March 2011

As the Dow advances from the mid-11600s toward 12400, the volume zone oscillator climbs from the zero line into the plus-40 buying-pressure zone, then loses that bid and crosses back through zero while the index peaks in mid-February and sells off into mid-March. The series was read from the VolumeZoneOsc pane of the eSignal screenshot, whose vertical scale is printed at 50 and 0.
As the Dow advances from the mid-11600s toward 12400, the volume zone oscillator climbs from the zero line into the plus-40 buying-pressure zone, then loses that bid and crosses back through zero while the index peaks in mid-February and sells off into mid-March. The series was read from the VolumeZoneOsc pane of the eSignal screenshot, whose vertical scale is printed at 50 and 0.Dow Jones Industrial Average · Daily bars · 2011-01-03T00:00:00.000Z to 2011-03-14T00:00:00.000Z

The pane does not print a lower-scale number. Points sit on the dated ticks and are rounded to the nearest 5 oscillator units; treat them as approximate.

A bullish sequence under the regime filter

A Bloomberg example marks a bullish setup when the oscillator crosses above zero on the last full bar below a 60-day exponential moving average, with the Average Directional Index near 18. Later in that sequence the oscillator recrosses above +15 as price gaps above that average and the Average Directional Index approaches 20.

Lookback as an explicit construction parameter

The eSignal formula exposes a single configurable lookback so the oscillator period can be changed from the chart editor. AmiBroker users can insert a ready formula and change the oscillator averaging period from the chart, showing the lookback as an explicit construction parameter rather than a fixed constant.

Regime-dependent rules in a later port

A Wealth-Lab port implements not only the oscillator but also regime-dependent system rules, including positive and negative price-oscillator divergences. Those divergences can be drawn as lines or as a binary wave for mechanical use.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
