Evaluating breakout and CCI rules as complete mechanical procedures

A historical study placed an original breakout procedure and an eleven-unit Commodity Channel Index oscillator on the same December 1991 S&P 500 series so both rule sets could be judged side by side as mechanical-trading-system procedures under shared fill timing and exit discipline.

  • An original breakout procedure and an eleven-unit Commodity Channel Index oscillator were placed on the same December 1991 S&P 500 series, observed from March through September, so the rule sets could be evaluated side by side.
  • Buy and sell entries and exits used next-open-fill, with execution on the open of the session after the signal rather than on the signal bar.
  • Oscillator trades used signal-to-signal-hold so the two procedures were not compared under unequal exit freedom.
  • The evaluation applied no stop orders. Omitted stops were a test-design choice, and a live implementation would typically add loss-limiting exits. Each trade was recorded as a point-result.
Entries in this reading3 entries
Current trackCommodity Channel Index40 readingsBreakout system48 readingsMechanical trading system158 readings

A shared series for two rule sets

The study placed an original breakout procedure and an oscillator procedure on the same market series so their rule sets could be evaluated side by side. The shared series was the December 1991 S&P 500 contract observed from March through September.

A breakout-system is a rules-based procedure that issues buy, sell, or stand-aside signals when price crosses a defined range or level. The oscillator specification used an 11-unit Commodity Channel Index. A commodity-channel-index is a lookback oscillator built from ordered price observations over a fixed sampling window and used here as an eleven-unit signal source.

A mechanical-trading-system is a complete, testable bundle of entry, exit, and abstention rules applied without discretionary overrides during the evaluation window.

Frozen fills and equal exit discipline

Buy and sell entries and exits were filled on the open of the session after the signal, not on the signal bar itself. That next-open-fill rule applied to both procedures, so fill timing was not a free variable in the comparison.

Oscillator trades were held until another signal appeared. That signal-to-signal-hold kept the oscillator from receiving independent exit freedom that the breakout procedure did not share.

Stops left out by design

The evaluation applied no stop orders. The write-up treats omitted stops as a test-design choice and notes that a live implementation would typically add loss-limiting exits.

Results recorded in points

Each trade result was recorded as a point-result, meaning points gained or lost rather than a dollar amount.

Points won or lost on each mechanical trade

Side-by-side bars show how the same thirteen-trade window treated the two complete procedures. The 11-unit CCI oscillator books large wins on trades 7–9 and finishes +36.20 points; the original breakout rule is almost entirely in the loss column and finishes −32.05. Each bar is the signed point result from the sidebar ledgers, filled on the next session’s open with no stops.
Side-by-side bars show how the same thirteen-trade window treated the two complete procedures. The 11-unit CCI oscillator books large wins on trades 7–9 and finishes +36.20 points; the original breakout rule is almost entirely in the loss column and finishes −32.05. Each bar is the signed point result from the sidebar ledgers, filled on the next session’s open with no stops.December 1991 S&P 500 · Daily · 1991-03-01T00:00:00.000Z to 1991-09-30T00:00:00.000Z

Oscillator positions stay open until the next signal so the two rule sets share the same exit discipline. Stops were omitted on purpose. Blank point cells were taken from the printed next-day opens (breakout trade 1: 374.90 to 376.65; oscillator trade 6: 383.00 to 378.70). Net dollars in the ledgers use $500 per S&P point.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
