Slow relative-strength index from an exponentially smoothed price

The slow relative-strength index replaces raw price with an exponential moving average, then applies an RSI-style net-change and total-change calculation to that series. Two independent lookbacks set the smoother and the oscillator, and side-by-side charts show a visibly smoother 0-100 line than a same-length relative-strength index.

  • The slow relative-strength index is built by replacing raw price with an exponential moving average, then running an RSI-style net-change and total-change calculation on that smoothed series.
  • A typical implementation keeps two independent lookbacks: a smoothing length for the exponential average of price, and an RSI length used as a constant of at least 1 for the oscillator averages.
  • Each new one-bar change and each new absolute change is blended with a smoothing factor equal to the reciprocal of the RSI length; the change ratio is net-change average over total-change average when the latter is nonzero, otherwise zero, then rescaled to a 0-100 index.
  • Side-by-side charts of the slow oscillator and a standard relative-strength index on the same daily index series show that the slow version is visibly smoother.
Entries in this reading3 entries
Current trackExponential smoothing183 readingsRelative Strength Index261 readingsMoving average597 readings

How the slow oscillator is built

The slow relative-strength index is constructed by first replacing raw price with an exponential moving average, then applying an RSI-style net-change and total-change calculation to that smoothed series. The oscillator therefore reads an exponentially smoothed price series rather than raw closes.

Two independent lookbacks

A typical implementation exposes two independent lookbacks. The smoothing length is the lookback of the exponential average applied to price before RSI-style change ratios are computed. The RSI length is the lookback that updates the net-change and total-change averages inside the oscillator, and it is used as a constant of at least 1.

Seeding and the recursive update

The oscillator update uses a smoothing factor equal to the reciprocal of the RSI length, recursively blending each new one-bar change and each new absolute change into running net-change and total-change averages.

On the first bar the net-change average is seeded as the price difference over the RSI length divided by that length. The total-change average is seeded as a simple average of absolute one-bar changes over the same length. That seed is a moving average of those absolute one-bar changes.

From the change ratio to the index

When the total-change average is nonzero, the change ratio equals the net-change average divided by the total-change average. Otherwise the ratio is set to zero. The indicator is then 50 times that ratio plus one, which rescales the change ratio to the 0-100 oscillator range.

A spreadsheet reconstruction

A spreadsheet reconstruction instead feeds the oscillator with the difference between the close and a moving average. It averages positive and negative differences over a 14-bar window and converts the resulting slow relative strength into a 0-100 index.

When the averages become available

Workbook variants such as SRSI (6,14), SRSI (8,14), and SRSI (8,17) change when the exponential average and the oscillator averages become available. An eight-period smoother starts after eight closes. The 14-bar and 17-bar oscillators start after 14 and 17 recorded differences respectively.

A calmer line than a same-length RSI

Side-by-side charts of the slow oscillator and a standard relative-strength index on the same daily index series are presented to show that the slow version is visibly smoother.

Slow RSI versus 14-day RSI on daily Magellan Health

Through Magellan Health’s spring 2015 advance the slow oscillator climbs once and then sits near 90, while the ordinary 14-day RSI keeps swinging between the mid-40s and low-70s; both drop with the early-May break. Interior readings were taken from the screenshot’s labeled pane grids; the last 13.32 and 28.56 are the platform’s own prints for 8 May 2015.
Through Magellan Health’s spring 2015 advance the slow oscillator climbs once and then sits near 90, while the ordinary 14-day RSI keeps swinging between the mid-40s and low-70s; both drop with the early-May break. Interior readings were taken from the screenshot’s labeled pane grids; the last 13.32 and 28.56 are the platform’s own prints for 8 May 2015.Magellan Health Services (MGLN) · Daily · 2015-02-02T00:00:00.000Z to 2015-05-08T00:00:00.000Z

Except for those two closing prints, every interior point is read from the Slow RSI grid at 96/80/64/32/16 and the RSI14 grid at 80/48/32, so values are only good to a few index units. The raster does not resolve each daily tick of the 14-day RSI.

Educational research material, not investment advice. Historical source context does not establish present-day performance.
